Halaman Product of Electric Vehicle Custom Production and Test-Conversion Workshop
| Overview | |
|---|---|
| Manufacturer | PUI-STP OTOMOTIF ITS |
| Production | 2020 |
| Price | - |
| Body and Chassis | |
| Class | Electric Bus |
| Body style | Medium size Bus |
| Layout | Mid Drive, Rear Wheel Drive |
| Frame Type | Ladder Frame |
| Battery and Charging | |
| Battery Capacity | 54 kWh, LiFePo4 Cell 3,2V 50Ah Battery Capacity |
| Charge Port | - |
| Port Location | - |
| Voltage | 540V |
| Charging Time | - |
| Dimensions and Weight | |
|---|---|
| Length | 7145 mm |
| Width | 2035 mm |
| Height | 1595 mm |
| Wheelbase | 3850 mm |
| Performance | |
| Top Speed | 110 km/h |
| Electric Range | - |
| Power | 115kW |
| Torque | 285 Nm - 550 Nm Peak |
| Drive train | Single Speed, Direct Transmission Electric Reverse |
| Other | |
| Rim | 16x6,00GS, 6 Studs |
| Front Tire | 7,50-16-14PR |
| Rear Tire | 7,50-16-14PR |
| Front Suspension | Long tappered leaf springs with shock absorber and stabilizier |
| Rear Suspension | Long tappered leaf springs with shock absorber and stabilizier |
| Front Brake | Hidrolic system with Vacuum Servo Assist |
| Rear Brake | Hidrolic system with Vacuum Servo Assist |
